Horizontal high volume packaging machine for packing in sacks SME

SME er en horisontal pakkemaskine designed til pakning styk og løst gods i sække.

Technical parameters
dose volume (liters) up to 100
output* (sacks/min.) up to 3
sack length (mm) 1360 and 1400
sack width (mm) 640 and 670
packing material half-sleeve, max. diameter of roll 450 mm
power supply 3 x 230V/400V - 50 Hz
power without filler (kW) 4,3
air pressure (MPa) from 0,6 to 0,8
air consumption at 0,6 MPa (liters/min.) 65
noise (dB) up to 75
machine weight (kg) 1100
dimensions H x W x L (mm) 2300 x 1040 x 8400

* Output is dependent on the dose size, kind of products and capacity of used filler.

Description
display of minute capacity
pneumatics Rexroth, Festo
electronics resistant to short circuit, reversing of polarity, overload
lifelong lubricant fills
electrical cover IP 44
shift of film by chain and belt
autodiagnostics
date printing by means of marking device MARK 1
all functions are set from control switchboard
areas which are in contact with the goods are made of stainless steel
all parts of the machine are protected health harmless surface treatment

Advantages
simple setting of function on control panel
atuo-check of most important parameters
delay in pulling of film for dusty wares
termination of operation after achieving of required number of sacks
screen counter of bags made till termination of operation
list of total number of cycles
simple design of drives

Accessories
belt conveyor
screw conveyor
discharge conveyor
photocell for print centring
labelling device
compressor 15 - 20 cubic meters
